TIME-SERT® M14 × 1.5 Metric Thread Repair Kit – 10 Inserts (14-Piece Set)
£292.25
| 🔧 | 🔧 | 🔧 | 🔧 | 🔧 |
The TIME-SERT® M14 × 1.5 Metric Thread Repair Kit is a professional 14-piece system designed to restore stripped or damaged internal threads. Includes four specialist installation tools and ten solid steel inserts in two lengths: 17.8mm and 26mm.
- M14 × 1.5 Thread Repair – Restores the original metric fine thread.
- Complete 14-Piece Kit – Four installation tools and ten inserts.
- Two Insert Lengths – Five 17.8mm and five 26mm inserts.
- Solid Steel Bushings – Flanged, mechanically self-locking design.
- Professional Repair System – For compatible automotive and engineering applications.
Restore damaged M14 × 1.5 threads with genuine TIME-SERT® – order your complete repair kit today!
Need additional inserts?
Shop TIME-SERT Metric Thread Repair Inserts →
Description
TIME-SERT® M14 × 1.5 Metric Thread Repair Kit – 10 Inserts (14-Piece Set)
The TIME-SERT® M14 × 1.5 Metric Thread Repair Kit is a professional 14-piece system designed to restore stripped, damaged or worn internal threads. Featuring solid steel bushings with positive seating flanges and mechanical self-locking technology, the kit restores the original M14 × 1.5 thread specification. Supplied with four specialist installation tools and ten inserts in two lengths: five measuring 17.8mm and five measuring 26mm.
Professional M14 × 1.5 Metric Thread Repair System
TIME-SERT® solid bushing inserts provide a durable solution for repairing damaged metric internal threads in compatible automotive, engineering and industrial components. The thin-wall design allows the original bolt diameter and pitch to be retained while restoring a reliable internal thread.
Each insert features an integrated flange for positive placement and a mechanical self-locking system. During installation, the dedicated driver cold-rolls the lower internal threads, expanding the corresponding external threads into the parent material to secure the insert.
This 14-piece kit includes two insert lengths, providing flexibility for repairs requiring different thread engagement depths. For other sizes, explore our TIME-SERT Metric Thread Repair Kits.
Key Features
- Complete 14-Piece System – Four specialist installation tools and ten solid steel inserts.
- Two Insert Lengths – Five 17.8mm inserts and five 26mm inserts.
- Original Thread Restoration – Repairs M14 × 1.5 metric fine internal threads.
- Positive Seating Flange – Provides accurate insert positioning and controlled installation depth.
- Mechanical Self-Locking – Cold-roll installation secures the insert within the repaired component.
Technical Specifications
- M14 × 1.5Metric Fine Thread
- 14 PiecesComplete Set
- 10 InsertsTwo Lengths
- 4 ToolsInstallation Tooling
| Specification | Value |
|---|---|
| Brand | TIME-SERT® |
| Product Type | Metric Thread Repair Kit |
| Internal Thread Size | M14 × 1.5mm |
| Thread Classification | Metric Fine |
| Insert Construction | Solid Steel Bushing |
| Short Insert Length | 17.8mm |
| Short Insert Quantity | 5 |
| Long Insert Length | 26mm |
| Long Insert Quantity | 5 |
| Total Inserts | 10 |
| Installation Tools | 4 |
| Total Physical Components | 14 |
| Insert Design | Thin-Wall, Flanged |
| Locking Method | Cold-Roll Mechanical Expansion |
| Application | Compatible Automotive, Engineering & Industrial Thread Repairs |
| Condition | New |
Kit Contents – 14 Pieces
- 5 × TIME-SERT® Inserts – M14 × 1.5 × 17.8mm.
- 5 × TIME-SERT® Inserts – M14 × 1.5 × 26mm.
- TIME-SERT® Drill Bit – Prepares the damaged hole.
- TIME-SERT® Counterbore Tool – Creates the seating recess for the insert flange.
- TIME-SERT® Tap – Cuts the required installation thread.
- TIME-SERT® Installation Driver – Installs and mechanically locks the insert.
Also Supplied: Instruction Manual and VAT Invoice. These are not included in the 14-piece component count.
Please Note: The kit includes ten inserts in two different lengths. Select the appropriate insert length for the available thread depth and repair requirements.
Why Choose TIME-SERT® M14 Thread Repair?
Restores Original Threads
Repairs damaged M14 × 1.5 internal threads while retaining the original bolt diameter and pitch.
Two Insert Lengths
Includes 17.8mm and 26mm inserts for compatible repairs requiring different thread engagement depths.
Positive Flange Placement
The integrated flange provides controlled seating and prevents the insert from winding deeper into the correctly prepared hole.
Mechanical Self-Locking
The dedicated driver cold-rolls the lower threads to mechanically secure the insert within the parent material.
Typical Applications
- Stripped or damaged M14 × 1.5 internal threads.
- Engine blocks and cylinder heads.
- Compatible automotive and commercial vehicle components.
- Transmission and gearbox housings.
- Industrial machinery and mechanical assemblies.
- Engineering workshop thread restoration.
- Repairs requiring different thread engagement depths.
Compatibility Note: Application suitability depends on the component design, available parent material, hole depth and installation clearance. Confirm that the original thread is M14 × 1.5 metric fine rather than M14 × 2.0 metric coarse.
Installation & Important Information
- Confirm: Verify the original M14 × 1.5 thread and select the appropriate insert length.
- Drill: Prepare the damaged hole using the supplied TIME-SERT drill bit.
- Counterbore: Create the seating recess for the insert flange.
- Tap: Cut the receiving thread using the dedicated TIME-SERT tap.
- Install: Fit the selected insert using the supplied installation driver.
- Lock: Complete the mechanical locking operation according to the manufacturer’s instructions.
Important: Always follow the official TIME-SERT installation instructions. Confirm sufficient hole depth and tool clearance, particularly when installing the longer 26mm inserts.
This is a standard TIME-SERT thread repair system, not a BIG-SERT oversize system. The inserts and installation tools are not interchangeable.
For safety-critical or heavily loaded applications, professional assessment and installation are recommended.
Complete Your Thread Repair
For replacement inserts, additional repair kits and compatible accessories, explore our professional TIME-SERT range.
- TIME-SERT Metric Thread Repair Inserts – Browse replacement solid bushings in various metric sizes and lengths.
- TIME-SERT Metric Thread Repair Kits – Explore complete repair systems for additional metric thread sizes.
- TIME-SERT Thread Repair Accessories – Discover related installation tooling and repair products.
Important: Always confirm insert length and tooling compatibility before purchasing replacement components.
Frequently Asked Questions
What thread size does this kit repair?
The kit is designed to restore compatible M14 × 1.5 metric fine internal threads.
How many inserts are included?
Ten inserts are supplied: five measuring 17.8mm and five measuring 26mm long.
What installation tools are included?
The kit includes a drill bit, counterbore tool, tap and installation driver.
Can I use this kit for M14 × 2.0 threads?
No. This kit is designed for M14 × 1.5 metric fine threads, not M14 × 2.0 metric coarse threads.
Is this a BIG-SERT oversize repair kit?
No. This is a standard TIME-SERT thread repair kit. BIG-SERT uses different oversize inserts and installation tooling.
Are replacement inserts available separately?
Yes. Browse our TIME-SERT metric replacement insert range and confirm the required thread size and length before ordering.
